Mahindra Bolero Pickup Loading Capacity 2026 — Payload, Body Size & Weight Limit (All Variants)
Quick Summary: Mahindra Bolero Pickup payload capacity ranges from 1,250 kg (Maxi Truck) to 1,700 kg (Extra Long). Body size: 8 to 9.2 feet long. Load area: 41-51 sq ft. GVW: 2,650-3,200 kg. Best for mandi vegetables, e-commerce, construction material, and FMCG distribution.
Understanding the exact loading capacity of your Bolero Pickup is critical — overloading damages suspension, reduces brake life, and voids warranty. Underloading means you're leaving money on the table. This guide covers every variant's rated payload, body dimensions, GVW (Gross Vehicle Weight), and practical advice on what you can actually carry legally and safely.
Advertisement
Payload Capacity — All Variants
| Variant | Payload (kg) | GVW (kg) | Kerb Weight |
| Bolero Maxi Truck (Base) | 1,250 kg | 2,650 kg | 1,400 kg |
| Bolero Maxi Truck Plus | 1,500 kg | 2,900 kg | 1,400 kg |
| Bolero Pickup Extra Long | 1,700 kg | 3,200 kg | 1,500 kg |
| Bolero Pickup Camper | 1,500 kg | 2,900 kg | 1,400 kg |
| Bolero Pickup Flat Bed | 1,700 kg | 3,200 kg | 1,500 kg |
| Bolero Pickup 4x4 | 1,250 kg | 2,750 kg | 1,500 kg |
Body Dimensions — Complete Measurements
| Variant | Length (ft) | Width (ft) | Height (ft) | Area (sq ft) |
| Maxi Truck (1.25T) | 8.0 | 5.2 | 1.4 | 41.6 |
| Maxi Truck Plus (1.5T) | 8.0 | 5.5 | 1.4 | 44.0 |
| Extra Long (1.7T) | 9.2 | 5.5 | 1.4 | 50.6 |
| Camper (Flat Bed) | 8.5 | 5.5 | — | 46.7 |
💡 Body Size Tip: The Extra Long (9.2 ft) is ideal for bulky but lighter goods — FMCG boxes, mattresses, appliances, e-commerce parcels. The standard 8 ft body is better for dense/heavy goods like vegetables, grains, and construction material where you hit the weight limit before filling the body.
What Can You Carry? — Practical Examples
| Cargo Type | Quantity (1.5T variant) | Notes |
| Vegetables (Mandi crates) | 50-60 crates | ~25 kg per crate |
| Rice/Wheat bags (50 kg) | 30 bags | = 1,500 kg exactly |
| Cement bags (50 kg) | 28-30 bags | Dense, fills weight first |
| Sand/Gravel | 1.5 cubic metres | ~1,500 kg |
| E-commerce boxes (avg 5 kg) | 200-300 boxes | Volume limited, not weight |
| FMCG cartons | 80-100 cartons | Light goods, fills space first |
| Furniture / Appliances | 3-4 large items | Fridge + washing machine + beds |
| Water cans (20L) | 75 cans | = 1,500 kg |
Overloading — Risks & Penalties
⚠️ Overloading Consequences:
- Legal penalty: ₹2,000-20,000 fine per trip if caught at checkpost
- Suspension damage: Leaf springs crack with 20%+ overloading
- Brake failure risk: Overloaded vehicles need 40% more stopping distance
- Tyre blowout: Heat buildup in overloaded tyres — common cause of accidents
- Warranty void: Mahindra won't cover any overloading-related damage
- Insurance claim rejected: Overloaded accident = no insurance payout
- Mileage drop: Every 100 kg overload costs 1-1.5 km/l
Advertisement
Loading Capacity Comparison — Segment
| Pickup | Payload | Body Length | Load Area |
| Bolero Pickup Extra Long | 1,700 kg | 9.2 ft | 50.6 sq ft |
| Bolero Maxi Truck Plus | 1,500 kg | 8.0 ft | 44.0 sq ft |
| Tata Intra V30 | 1,500 kg | 8.5 ft | 47.0 sq ft |
| Ashok Leyland Dost+ | 1,500 kg | 8.2 ft | 45.0 sq ft |
| Tata Ace Gold | 1,000 kg | 7.0 ft | 35.0 sq ft |
| Mahindra Jeeto Plus | 750 kg | 6.5 ft | 30.0 sq ft |
The Bolero Pickup Extra Long has the highest payload in the sub-4T pickup segment at 1,700 kg. The 9.2 ft body also gives maximum load area (50.6 sq ft) — ideal for volume goods. For pure payload-to-price ratio, it's the best value in the market.
🔥 Loading Accessories
Frequently Asked Questions
What is the maximum loading capacity of Mahindra Bolero Pickup?
Maximum rated payload is 1,700 kg in the Extra Long and Flat Bed variants. Maxi Truck base carries 1,250 kg and Maxi Truck Plus carries 1,500 kg. The 4x4 variant carries 1,250 kg.
What is the body size of Bolero Pickup in feet?
Body length ranges from 8 feet (Maxi Truck) to 9.2 feet (Extra Long). Width is 5.2-5.5 feet. Load area is 41-51 square feet depending on variant.
How many bags can Bolero Pickup carry?
The 1.5T variant can carry 30 bags of 50 kg each (rice/wheat/cement). That's exactly 1,500 kg. Don't exceed this — overloading damages suspension and voids warranty.
Which Bolero Pickup variant has maximum load?
Bolero Pickup Extra Long (1.7T) has the maximum payload at 1,700 kg with 9.2 ft body length and 50.6 sq ft load area. It costs ₹8.6 lakh on-road.
What happens if I overload Bolero Pickup?
Overloading risks: ₹2,000-20,000 fine, suspension/spring damage, brake failure, tyre blowout, warranty void, insurance claim rejected, and 1-1.5 km/l mileage loss per 100 kg extra.
