Mahindra Bolero Pickup Loading Capacity — Payload, GVW & Body Size Guide
📌 Quick Summary — Bolero Pickup Loading Capacity:
• Payload range: 1300 kg to 1700 kg (depending on variant)
• Body sizes: 7 ft (City), 8 ft (Standard), 9 ft (Maxi Truck)
• GVW range: 3800 kg to 4140 kg
• Cement bags per trip: 26-34 bags (depending on variant)
• Overloading fine: ₹2,000 first offence, ₹10,000 repeat (MV Act)
• Rule: Never exceed registered GVW — it voids warranty and insurance
Understanding Bolero Pickup loading capacity is critical before buying. Many first-time buyers confuse payload with GVW, don't know what fits in which body size, or risk heavy fines by overloading. This complete guide explains payload by variant, body dimensions, GVW meaning, real-world examples of what fits, overloading risks and fines, smart loading tips, and body type options available for different cargo types.
Advertisement
Payload Capacity by Variant
| Variant | Payload | GVW | Kerb Weight |
| Bolero Pickup 1.3T FB | 1300 kg | 3700 kg | 2400 kg |
| Bolero City Pickup | 1400 kg | 3800 kg | 2400 kg |
| Bolero Pickup 1.5T | 1500 kg | 3900 kg | 2400 kg |
| Bolero Pickup 1.7T | 1700 kg | 4140 kg | 2440 kg |
| Bolero Maxi Truck | 1700 kg | 4140 kg | 2440 kg |
| Bolero Maxi Truck Plus | 1700 kg | 4140 kg | 2440 kg |
| Bolero Pickup 4x4 | 1500 kg | 4050 kg | 2550 kg |
Body Dimensions — All Variants
| Variant | Length | Width | Height |
| City Pickup (7 ft) | 2100 mm | 1520 mm | 380 mm |
| Standard (8 ft) — 1.3T/1.5T/1.7T | 2430 mm | 1620 mm | 380 mm |
| Maxi Truck (9 ft) | 2750 mm | 1620 mm | 380 mm |
| Maxi Truck Plus (9 ft, high-side) | 2750 mm | 1620 mm | 450 mm |
The body height mentioned is the standard drop-side wall height. You can add extensions (taller sides, cage structures) from aftermarket body builders to increase volume capacity for light, bulky goods.
GVW Explained — What It Means for You
📐 GVW (Gross Vehicle Weight) = Kerb Weight + Payload + Driver + Fuel
• Kerb Weight: Weight of empty vehicle with full tank and all fluids (2400-2550 kg)
• Payload: Maximum weight of cargo you can load (1300-1700 kg)
• Driver + Fuel: Already accounted for in the GVW calculation (~100 kg)
• Important: GVW is printed on your RC (Registration Certificate). Police and RTO check this at weighbridges.
• Rule: Total loaded weight on weighbridge must NOT exceed registered GVW
What Fits? Real-World Loading Examples
| Cargo Type | Weight Each | Fits in 1.5T | Fits in 1.7T |
| Cement Bags (50 kg) | 50 kg | 30 bags | 34 bags |
| Rice/Wheat Sacks (50 kg) | 50 kg | 30 sacks | 34 sacks |
| Bricks (standard) | 3.5 kg | ~430 bricks | ~485 bricks |
| Water Cans (20L) | 20 kg | 75 cans | 85 cans |
| LPG Cylinders (14.2 kg) | 30 kg (full) | 50 cylinders | 56 cylinders |
| Vegetable Crates (20 kg) | 20 kg | 75 crates | 85 crates |
| Sand (loose, per trip) | — | ~1 cu.m | ~1.1 cu.m |
| Iron/Steel Rods | varies | 1500 kg max | 1700 kg max |
* These are weight-limited numbers. Actual count may be lower if body volume fills up first (especially for bulky items like vegetable crates).
Overloading Risks & Fines
Overloading is the #1 reason for premature vehicle failure, accidents, and heavy fines in India. Here's what happens if you exceed the registered GVW:
- Fine — First offence: ₹2,000 + ₹1,000 per extra tonne (Motor Vehicles Act Section 194)
- Fine — Repeat offence: Up to ₹10,000 + impoundment of vehicle
- Insurance void: If accident happens while overloaded, insurance company WILL reject your claim
- Warranty void: Mahindra won't cover suspension, axle, or chassis damage if overloaded
- Suspension damage: Leaf springs crack, shock absorbers fail — repair cost ₹15,000-25,000
- Brake failure: Overloaded trucks take 40% longer to stop — #1 cause of rear-end accidents
- Tyre burst risk: Overloading heats tyres beyond rated capacity — blowout risk increases 3x
- Frame fatigue: Chassis develops micro-cracks over time — repair not possible, vehicle scrapped
⚠️ Critical Warning: Many owners load 2000-2200 kg on a 1.5T or 1.7T variant regularly. While the truck "handles" it initially, after 1-2 years the rear axle, leaf springs, and chassis show fatigue. Repair costs exceed ₹50,000 and resale value drops 30%. It's never worth it.
Smart Loading Tips
- Distribute weight evenly: Heavy items at bottom, center of cargo bed. Never load one side heavier.
- Don't stack above sides: Cargo above side walls shifts during braking — use ropes/nets if stacking.
- Know your goods' density: Sand/cement fills weight limit fast. Vegetables/parcels fill volume first.
- Use weighbridge before highway: ₹20-50 per weigh — cheaper than ₹10,000 fine at checkpost.
- Adjust tyre pressure for load: Increase rear tyre pressure by 5 PSI when loaded (check manual).
- Secure loose goods: Use cargo nets, ropes, or tarpaulin. Unsecured goods damage during transit.
- Account for body weight: Aftermarket high-side bodies add 100-150 kg — this reduces your effective payload.
Advertisement
Body Types Available for Bolero Pickup
| Body Type | Best For | Cost |
| Standard Drop-Side | General goods, bags, crates | Included |
| Flat Bed (no sides) | Pipes, rods, custom cargo | Included (1.3T FB) |
| High-Side Body | Loose vegetables, grains | ₹8,000-12,000 |
| Full Closed Container | E-commerce, FMCG, rain protection | ₹25,000-40,000 |
| Cage/Wire Mesh Body | Gas cylinders, poultry, livestock | ₹15,000-20,000 |
| Water Tank | Water supply business | ₹18,000-30,000 |
| Refrigerated Body | Frozen food, dairy, ice cream | ₹80,000-1.5 L |
Most body modifications are done through Mahindra-authorized body builders or local fabricators. Ensure your body builder provides a weight certificate — this is important to know the exact payload left for cargo after body weight is deducted.
Recommended Accessories for Loading & Safety
Essential accessories for Bolero Pickup loading operations — improve safety and driver comfort:
Dylect 4K Dash Cam — Dual Channel with Sony STARVIS 2
4K front + 1080p rear recording, ADAS safety alerts, GPS tracking, Wi-Fi, night vision, 140° wide angle. Essential for insurance claims & driver monitoring.
₹5,000 - ₹8,000
🛒 Buy on Amazon
Eliane Steering Wheel Power Knob — 360° Rotation Spinner
Non-slip ABS grip, 360° steering booster for trucks & tractors. Makes U-turns and parking effortless. Reduces driver fatigue on long hauls.
₹200 - ₹500
🛒 Buy on Amazon
Woschmann 12V DC Double Head Fan — 360° Rotatable
Dual fan heads, 2-speed control, 360° rotation. Keeps cabin cool in non-AC trucks during summer. Direct 12V connection — no inverter needed.
₹600 - ₹1,200
🛒 Buy on AmazonAffiliate Disclosure: We may earn a small commission if you purchase through these links at no extra cost to you. This helps us keep OnRoadCost free and updated.
Pros & Cons — Bolero Pickup Loading
✅ Pros
- 1.7T payload — best in mini-truck/pickup segment
- Multiple body sizes (7/8/9 ft) for different needs
- Heavy-duty suspension on 1.7T handles consistent loads
- Low loading height — easy manual loading/unloading
- Wide aftermarket body options available
- Flat bed option (1.3T FB) for custom body work
- Reinforced chassis handles Indian road conditions
- High ground clearance works on uneven loading sites
❌ Cons
- Standard body sides only 380mm — limits loose cargo
- No hydraulic tipping — manual unloading only
- 63 bhp struggles at full load on steep inclines
- Mileage drops 30-40% at maximum payload
- Aftermarket bodies add 100-150 kg reducing effective payload
- No crane or lift mechanism available
- Overloading temptation due to reliable chassis
- Suspension stiff when empty (designed for loaded use)
📋 Compare Bolero Pickup loading capacity with other trucks
Compare Trucks →Frequently Asked Questions
What is the maximum loading capacity of Bolero Pickup?
The maximum loading capacity (payload) of Bolero Pickup is 1700 kg in the 1.7T, Maxi Truck, and Maxi Truck Plus variants. The 1.5T carries 1500 kg and the 1.3T FB carries 1300 kg.
How many cement bags can Bolero Pickup carry?
The Bolero Pickup 1.5T can carry 30 cement bags (50 kg each = 1500 kg). The 1.7T variant can carry 34 bags. Never exceed the rated payload to avoid fines and vehicle damage.
What is GVW of Bolero Pickup?
GVW (Gross Vehicle Weight) of Bolero Pickup ranges from 3700 kg (1.3T FB) to 4140 kg (1.7T/Maxi Truck). GVW = vehicle weight + payload + driver + fuel. Your total loaded weight must never exceed this.
What is the fine for overloading Bolero Pickup?
First offence: ₹2,000 + ₹1,000 per extra tonne (Section 194, MV Act). Repeat offence: up to ₹10,000 + vehicle impoundment. Additionally, insurance claims are void if accident happens while overloaded.
What is the body size of Bolero Pickup?
Standard body (1.3T/1.5T/1.7T): 2430 x 1620 x 380 mm (8 ft). Maxi Truck: 2750 x 1620 x 380 mm (9 ft). City Pickup: 2100 x 1520 x 380 mm (7 ft). High-side and custom bodies available.
Can I put a closed container body on Bolero Pickup?
Yes. Closed container bodies are available from ₹25,000-40,000 through authorized body builders. They add 100-150 kg to the vehicle weight, reducing effective payload. Great for rain protection and e-commerce delivery.
